Disc wood chipper
Introduction
Disc wood chipper machine is widely used in paper mills, particleboard mills, fiberboard mills and wood chip processing bases. Logs, small-diameter wood, etc. can be cut into industrial wood chips with uniform length, flat cuts and uniform thickness, and can also cut ya wood, boards, etc.
The large disc wood chipper has two types: pulley drive and direct drive; the feeding is divided into horizontal and inclined modes, and the discharging also has two modes: upper discharge and lower discharge.






Materials&Usage&Sizes


86% Visitors ENQUIRED NOW and Got the Following Gifts Freely
1. 2021 Full Catalogue
2. 2021 Full Price List
3. Technical Brochure
4. Operation Manual
5. A Surprising Discount
6. Some Free Accessories
Features&Advantages

8mm thick steel plate inlet

China top WuXing engine, pure copper coil, service life can reach more than 10 years

Optional wheels and traction device, hand jack, mobile operation anytime&anywhere

Alloy Steel Hammer, long wear-resistant service life, high cutting efficiency

Three optional power modes: electric motor, gasoline engine, diesel engine

Three-layers spray paint, 20 years of anti-rust, paint color can be customized

The machine body is made of 5mm thick steel plate, long service life

Widely used in particle board, papermaking raw materials, transportation filling, animal nest filling, bioenergy
86% Visitors ENQUIRED NOW and Got the Following Gifts Freely
1. 2021 Full Catalogue
2. 2021 Full Price List
3. Technical Brochure
4. Operation Manual
5. A Surprising Discount
6. Some Free Accessories
Parameters
MODEL | POWER(KW) | OUTPUT(KGS) | ROLLER BLADE(PCS) | MAXIMUM CRUSHING DIAMETER(CM) | CARTON SIZE(MM) & GROSS WEIGHT(KG) |
---|---|---|---|---|---|
AKQ-420 | 7.5 | 1000 | 3 | 13 | ELECTRIC MOTOR:1350*700*900,220KG DIESEL ENGINE:1920*700*990, 250KG,15HP |
AKQ-600 | 15 | 3000 | 3 | 15 | ELECTRIC MOTOR:1650*750*1100,450KG DIESEL ENGINE:2200*750*1200, 550KG,28HP |
AKQ-800 | 30 | 5000 | 4 | 20 | ELECTRIC MOTOR:1950*850*1340,830KG DIESEL ENGINE:2300*850*1450, 950KG,40HP |
AKQ-950 | 37 | 8000 | 4 | 22 | ELECTRIC MOTOR:2050*950*1600, 1250KG DIESEL ENGINE:2600*1150*1700, 1450KG, 60HP |
AKQ-1150 | 55 | 10000 | 4 | 25 | ELECTRIC MOTOR:2660*1250*1900, 2500KG DIESEL ENGINE:2860*1350*2000, 2800KG,80HP |
AKQ-1410 | 90 | 12000 | 4 | 30 | ELECTRIC MOTOR:3000*1500*2200, 3200KG DIESEL ENGINE:3200*1700*2200, 3500KG,155HP |
Package&Transportation

Disc Type Wood Chipper Machine is wraped 5 layers of plastic film to avoid moisture and bumps

Thickened pallets and wooden boxes for export to protect the Disc Type Wood Chipper Machine from damage

By sea, rail, and air, Disc Wood Chipper Machine will be delivered to you in time within 7-30 days
