Branch crusher machine
Úvod
Tree branch crusher machine is also called a wood branch crusher, which integrates slicing and crushing. Branch crusher can cut branches with a chip diameter of 1-20 cm. Tree branch crusher is mainly used to process pine, miscellaneous wood, poplar wood, fir, raw bamboo and other materials.
Branch crusher machine is suitable for machining sawdust in edible fungus culture medium. At the same time, the equipment can also be used for cutting fiber stalk-like materials such as bamboo, thatch, corn stalk, sorghum stalk, atd.
Materials&Usage&Sizes
86% Návštěvníci POPTÁVANÁ HNED a mám následující Dárky zdarma
1. 2021 Plný Katalog
2. 2021 Plný Ceník
3. Technický Brožura
4. Úkon Manuál
5. Překvapivé Sleva
6. Nějaký Zdarma příslušenství
Features&Advantages
Detachable 360-degree rotating discharge port
More Wide and deep foldable inlet
China top Weichai engine, turbocharged, water-cooled, stable performance
Alloy Steel Hammer, long wear-resistant service life, high cutting efficiency
Aluminum alloy wheels with large tires, not easy to fall into the mud
Equipped with traction device&hand jack, mobile operation anytime&anywhere
Three-layers spray paint, 20 years of anti-rust, paint color can be customized
Two start methods: electric start + hand crank
The feed throat automatically squeezes and conveys the feed with hydraulic pressure, no splashing, and safe operation
Accessories include Portable tool box and a set of engine belt
86% Návštěvníci POPTÁVANÁ HNED a mám následující Dárky zdarma
1. 2021 Plný Katalog
2. 2021 Plný Ceník
3. Technický Brožura
4. Úkon Manuál
5. Překvapivé Sleva
6. Nějaký Zdarma příslušenství
Parametry
| SPECIFICATION/MODEL | AK-6130 | AK-6145 |
|---|---|---|
| ROLLER WHEEL DIAMETER | 300MM | 500MM |
| NAPÁJENÍ | 22KW | 74KW |
| START-UP MODE | ELECTRIC | ELECTRIC |
| SPEED | 2200R/MIN | 1800R/MIN |
| NUMBER OF BLADES | 3 MOVABLE BLADES, 1 FIXED BLADES | 6 MOVABLE BLADES, 1 FIXED BLADES |
| BLADE LENGTH | 300MM | 230MM |
| INCOMING ROLLER DIAMETER | 280MM | 600MM |
| FEEDING GEAR | START, STOP AND REVERSE, THREE-SPEED MANUAL CONTROL | START, STOP AND REVERSE, THREE-SPEED MANUAL CONTROL |
| FEED THROAT DIMENSIONS | 300*200MM | 450*380MM |
| GENERATOR POWER | 600W | 600W |
| BATTERY POWER | 12V105AH | 24V105AH |
| OUTFALL SYSTEM | DETACHABLE 360-DEGREE ROTATING DISCHARGE PORT | DETACHABLE 360-DEGREE ROTATING DISCHARGE PORT |
| CUTTING SYSTEM | ROLLING LONGITUDINAL CUTTING | ROLLING LONGITUDINAL CUTTING |
| PRODUCTION ABILITY | 1-2T/H | 3-5T/H |
| MOVING WAYS | FOLDABLE HAND JACK, TOWING TYPE | FOLDABLE HAND JACK, TOWING TYPE |
| PACKING DIMENSIONS | 2450*1430*1330MM | 4000*1600*1700MM |
Package&Transportation
Tree branch crusher machine is wraped 5 vrstvy plastové fólie, aby se zabránilo vlhkosti a nárazům
Thickened pallets and wooden boxes for export to protect the Tree branch crusher machine from damage
U moře, železniční, a vzduch, branch crusher machine will be delivered to you in time within 7-30 dní
